CPRINTF displays styled formatted text in the Command Window. More...

Functions
function count =	cprintf (style, format, varargin)
	CPRINTF displays styled formatted text in the Command Window. More...

function [ underlineFlag , boldFlag , style ] =	cprintf>processStyleInfo (style)

function styleName =	cprintf>getColorStyle (rgb)

function delta =	cprintf>getUrlsFix (docElement)

function	cprintf>fixHyperlink (docElement)

function	cprintf>setElementStyle (docElement, style, specialFlag, majorVersion, minorVersion)

function	cprintf>dumpElement (docElements)

function cells =	cprintf>m2c (data)

function	cprintf>showDemo (majorVersion, minorVersion)

Detailed Description

CPRINTF displays styled formatted text in the Command Window.

Definition in file cprintf.m.

Function Documentation

function count = cprintf	(	style,
		format,
		varargin
	)

CPRINTF displays styled formatted text in the Command Window.

Syntax: count = cprintf(style,format,...)

Description: CPRINTF processes the specified text using the exact same FORMAT arguments accepted by the built-in SPRINTF and FPRINTF functions.

CPRINTF then displays the text in the Command Window using the specified STYLE argument. The accepted styles are those used for Matlab's syntax highlighting (see: File / Preferences / Colors / M-file Syntax Highlighting Colors), and also user-defined colors.

The possible pre-defined STYLE names are

   <tt>Text</tt>                 - default: black
   <tt>Keywords</tt>             - default: blue
   <tt>Comments</tt>             - default: green
   <tt>Strings</tt>              - default: purple
   <tt>UnterminatedStrings</tt>  - default: dark red
   <tt>SystemCommands</tt>       - default: orange
   <tt>Errors</tt>               - default: light red
   <tt>Hyperlinks</tt>           - default: underlined blue

   <tt>Black</tt>,<tt>Cyan</tt>,<tt>Magenta</tt>,<tt>Blue</tt>,<tt>Green</tt>,<tt>Red</tt>,<tt>Yellow</tt>,<tt>White</tt>

STYLE beginning with - or _ will be underlined. For example: -Blue is underlined blue, like Hyperlinks; _Comments is underlined green etc.

STYLE beginning with * will be bold (R2011b+ only). For example: *Blue is bold blue; *Comments is bold green etc. Note: Matlab does not currently support both bold and underline, only one of them can be used in a single cprintf command. But of course bold and underline can be mixed by using separate commands.

STYLE also accepts a regular Matlab RGB vector, that can be underlined and bolded: -[0,1,1] means underlined cyan, *[1,0,0] is bold red.

STYLE is case-insensitive and accepts unique partial strings just like handle property names.

CPRINTF by itself, without any input parameters, displays a demo

Example: cprintf; % displays the demo cprintf(text, regular black text); cprintf(hyper, followed s,by); cprintf(key, d colored, 4); cprintf(-comment,& underlined); cprintf(err, elements); cprintf(cyan, cyan); cprintf(_green, underlined green); cprintf(-[1,0,1], underlined magenta); cprintf([1,0.5,0],and multi- line orange); cprintf(*blue, and bold (R2011b+ only)); cprintf(string); % same as fprintf(string) and cprintf(text,string)

Bugs and suggestions: Please send to Yair Altman (altmany at gmail dot com)

Warning: This code heavily relies on undocumented and unsupported Matlab functionality. It works on Matlab 7+, but use at your own risk!

A technical description of the implementation can be found at: http://UndocumentedMatlab.com/blog/cprintf/

Limitations

In R2011a and earlier, a single space char is inserted at the beginning of each CPRINTF text segment (this is ok in R2011b+).
In R2011a and earlier, consecutive differently-colored multi-line CPRINTFs sometimes display incorrectly on the bottom line.

As far as I could tell this is due to a Matlab bug. Examples: >> cprintf(-str,under ^line); cprintf(err,red); % hidden red, unhidden _ >> cprintf(str,regu lar); cprintf(err,red); % underline red (not purple) lar

Sometimes, non newline ()-terminated segments display unstyled (black) when the command prompt chevron (>>) regains focus on the continuation of that line (I can't pinpoint when this happens). To fix this, simply newline-terminate all command-prompt messages.
In R2011b and later, the above errors appear to be fixed. However, the last character of an underlined segment is not underlined for some unknown reason (add an extra space character to make it look better)
In old Matlab versions (e.g., Matlab 7.1 R14), multi-line styles only affect the first line. Single-line styles work as expected. R14 also appends a single space after underlined segments.
Bold style is only supported on R2011b+, and cannot also be underlined.

Change log: 2012-08-09: Graceful degradation support for deployed (compiled) and non-desktop applications; minor bug fixes 2012-08-06: Fixes for R2012b; added bold style; accept RGB string (non-numeric) style 2011-11-27: Fixes for R2011b 2011-08-29: Fix by Danilo (FEX comment) for non-default text colors 2011-03-04: Performance improvement 2010-06-27: Fix for R2010a/b; fixed edge case reported by Sharron; CPRINTF with no args runs the demo 2009-09-28: Fixed edge-case problem reported by Swagat K 2009-05-28: corrected nargout behavior sugegsted by Andreas G�b 2009-05-13: First version posted on MathWorks File Exchange

See Also: sprintf, fprintf

Definition at line 17 of file cprintf.m.

References all().

Referenced by MUnit.RunClassTests(), models.BaseFirstOrderSystem.setConfig(), and approx.BaseApprox.test_ApproxProjections().

Here is the call graph for this function:

Here is the caller graph for this function:

function cprintf>dumpElement ( docElements )

Definition at line 521 of file cprintf.m.

References t.

function cprintf>fixHyperlink ( docElement )

Definition at line 407 of file cprintf.m.

function styleName = cprintf>getColorStyle ( rgb )

Definition at line 385 of file cprintf.m.

function delta = cprintf>getUrlsFix ( docElement )

Definition at line 395 of file cprintf.m.

function cells = cprintf>m2c ( data )

Definition at line 577 of file cprintf.m.

function [underlineFlag , boldFlag , style ] = cprintf>processStyleInfo ( style )

Definition at line 298 of file cprintf.m.

References all().

Here is the call graph for this function:

function cprintf>setElementStyle	(	docElement,
		style,
		specialFlag,
		majorVersion,
		minorVersion
	)

Definition at line 437 of file cprintf.m.

function cprintf>showDemo	(	majorVersion,
		minorVersion
	)

Definition at line 583 of file cprintf.m.
