Util: Utility functions for export of matrices and vectors to files. More...

Detailed Description

Util: Utility functions for export of matrices and vectors to files.

Documentation Update:

Author: Daniel Wirtz

Date: 2013-07-23

New in 0.7:: (Daniel Wirtz, 2013-07-23) Added this class.

This class is part of the framework

KerMor - Model Order Reduction using Kernels

Homepage http://www.morepas.org/software/index.html
Documentation http://www.morepas.org/software/kermor/index.html
License KerMor license conditions

Definition at line 17 of file Util.m.

Static Public Member Functions
static function	saveRealMatrix (mat, file, folder)
	Stores a real double matrix in little endian format. More...

static function	saveRealVector (vec, file, folder)
	Stores a real double vector in little endian format. More...

static function char jsonobj =	matrixToJSON (double value)
	Takes a matrix and returns a JSON representation as JSONObject with the fields "dim" and "values". More...

Static Public Attributes
static const	MachineFormat = "ieee-be"
	The machine format (little/big endian, 32/64bit) to use upon export. More...

Member Function Documentation

function char jsonobj = Util.matrixToJSON ( double value )

static

Takes a matrix and returns a JSON representation as JSONObject with the fields "dim" and "values".

The elements are stored inside the values array as double values, iterating through the (multi-dimensional) matrix in the order of the dimensions given in "dim". For a simple matrix this is a column-wise from left to right storage.

Parameters

value A double matrix

Return values

jsonobj A string representation of a JSON object

Definition at line 140 of file Util.m.

Referenced by kernels.KernelExpansion.toJSON().

Here is the caller graph for this function:

function Util.saveRealMatrix	(	mat,
		file,
		folder
	)

static

Stores a real double matrix in little endian format.

The first 64bits are used to encode the row and column numbers as int32, then the next bytes contain rows*cols*8bytes of double values. The matrix is addressed linearly in a row-wise fashion, i.e. first row, second row ...

Definition at line 52 of file Util.m.

References MachineFormat, and t.

Referenced by create_testdata(), and kernels.KernelExpansion.exportToDirectory().

Here is the caller graph for this function:
